Fluid Components International
The ST100 Series Flow Meter sets a new industry benchmark in process and plant air/gas flow measurement, delivering unsurpassed adaptability and value to meet plant gas flow measurement applications for today and tomorrow.
The ST100 Flow Meter’s graphical, multivariable, backlit LCD display/readout brings new meaning to the term “process information”. It provides the industry’s most comprehensive information with continuous display of all process measurements and alarm status, and the ability to interrogate for service diagnostics.
The user-friendly ST100 stores up to five unique calibration groups to accommodate broad flow ranges, differing mixtures of the same gas and multiple gases, and obtains up to 1000:1 turndown. An optional, patent-pending SpectraCal Gas Equivalency calibration method lets users select and switch between 10 common gases. An on-board data logger with an easily accessible, removable 2-GB micro-SD memory card capable of storing 21 million readings comes standard.
The ST100 offers three different types of flow sensors to best match user applications. The fast-response FPC-style is a fast response features an integral flow conditioner and protective shroud optimized for compressed air and clean gas applications. The fast-response, general purpose FP-style features a protective shroud and is the sensor used with FCI’s VeriCal in-situ calibration option. For wet or dirty gases, or erratic flows, the unshrouded S-style facilitates easy cleaning and provides a smoothed response.
The ST100 can be calibrated to measure virtually any process gas, including wet gas, mixed gases and dirty gases. The basic insertion style air/gas meter features a thermal flow sensing element that measures flow from 0.25 to 1000 SFPS (0.07 NMPS to 305 NMPS) with accuracy of ±0.75 percent of reading, ±0.5 percent of full scale.
Designed for rugged industrial processes and plants, ST100 Flow Meters include service up to 850ºF and are available with both integral and remote (up to 1000 feet) electronics versions. The ST100 is agency approved for hazardous environments, including the entire instrument, the transmitter and the rugged, NEMA 4X/IP67 rated enclosure. Instrument approvals in addition to ATEX and IECEx include FM and FMc.
