Plastics in Electrical Waste: Disposal or Recycling?

Every year, the editors of the scientific journal Environmental Science & Technology, select the best papers among their peer-reviewed contributions, which numbered more than 1500 in 2011 alone. This year, a contribution by Empa researchers has been awarded the title "Best Paper" in the "Policy Analysis" category. The scientists studied the proportion of restricted substances found in plastic components from waste electrical and electronic equipment.

Electrical and electronic appliances are not only made from metallic materials, but also consist of up to more than 20 percent of plastics in average. These are found, for example, in casings or in base materials for circuit boards. No simple task for recycling companies, which find themselves confronted with a growing amount of electrical and electronic waste, as plastics from scrap electrical and electronic equipment are rather diverse and may contain hazardous substances. Depending on the type of plastic and its application, they contain brominated flame retardants and other additives which may result in increased heavy metal concentrations. If certain legally defined maximum concentration values are exceeded, recycling has to be ruled out unless further action is taken.

In order to achieve the highest possible plastic recycling rate, recycling companies therefore need to know how hazardous substances are distributed among the different categories and types of electrical and electronic equipment (for example large household appliances or consumer electronics. The WEEE Forum – a not-for-profit association of 42 waste electrical and electronic equipment (WEEE) producer responsibility organisations (or compliance schemes) from 24 countries in Europe – therefore commissioned a team from the Technology and Society Lab at Empa to determine the actual concentrations of cadmium, (hexavalent) chromium, lead and mercury as well as of certain restricted brominated flame retardants (as PentaBDE, OctaBDE, DecaBDE, PBB) in plastics from disassembled scrap electrical and electronic equipment in Europe. For these metals and flame retardants, maximum permissible concentrations in new electrical and electronic equipment have been defined in an EU directive with the abbreviation RoHS (Restriction of Hazardous Substances), which came into force on July 1, 2006.

Looking for evidence of harmful substances in electrical waste

The three Empa researchers, Patrick Wäger, Mathias Schluep and Esther Müller, with assistance from Bachema AG in Schlieren, Switzerland, studied a total of 53 mixed plastic samples from 15 European countries.

The results showed that none of the equipment groups is entirely without problems: Brominated flame retardants or heavy metals were found in all the mixed plastics from disassembled electrical and electronic equipment, though concentration levels varied.

Particularly high concentrations of restricted brominated flame retardants were found in plastic rear panels from cathode ray tube monitors, whereas these substances could almost not be detected in plastic rear panels from flat screen monitors. High concentrations of heavy metals were found in mixed plastics from small domestic appliances (cadmium), information and communications technology (lead) and consumer electronics (lead). The researchers assume that the increased concentrations of lead, in particular, are primarily the result of cross-contamination from mechanical processing (lead from solder). In order to prevent these substances from dissipating into the environment or into components for new products, the researchers recommend that plastics from the processing of electrical and electronic equipment should be subject to strict quality management until such time as they are disposed of or recycled.

Results of the study incorporated into new standard

The results from the study have been incorporated into the new European WEEELABEX (WEEE LABel of EXcellence) standard, which governs the collection, sorting, storage, transport, reuse, treatment and disposal of electrical and electronic equipment. The editors of Environmental Science & Technology – the most cited journal in the environmental engineering and environmental sciences category – expect the paper to have a significant and long-lasting influence on the field and award it the title Best Policy Analysis Paper of 2011 in the first April issue of the journal.
