University Constructing 2.8-Megawatt Fuel Cell that Runs on Waste Methane
The renewable-energy project will turn waste methane gas from the Point Loma Wastewater Treatment Plant directly into electricity without combustion.
Construction of a fuel cell with enough capacity to power 2,800 homes has begun on the University of California’s San Diego campus as part of a renewable-energy project to turn waste methane gas from the Point Loma Wastewater Treatment Plant directly into electricity without combustion.
When completed in late 2011, the 2.8-megawatt fuel cell will be the largest on any college campus, providing about 8 percent of UC San Diego’s total energy needs. The $19 million project requires no university funding: It is eligible for $7.65 million in state Self-Generation Program incentives, and BioFuels Energy will provide the remaining $11.35 million in private investment, loans, and investment tax credits.
“Our campus currently generates 85 percent of its own power. With this new fuel cell and the near-doubling of our photovoltaic solar capacity in 2011, our campus will be able to meet as much as 95 percent of our annual electricity needs,” said Gary C. Matthews, vice chancellor of Resource Management and Planning. “The fact that we’ve been able to significantly increase our renewable-energy capacity in very challenging economic times with an innovative public-private partnership is as much a financial feat as it is an engineering accomplishment.”
As part of a 10-year agreement, UC San Diego will buy the electricity produced by the fuel cell from BioFuels Energy at competitive rates. The university’s fuel cell also offers the potential benefits of cogeneration, or combined heat and power, in which waste heat can be tapped as a secondary power source, raising the overall net efficiency of the fuel cell to about 60 percent, compared to about 33 percent for coal- and oil-fired power plants.
About 85 percent of the university’s energy needs are provided by its low-emission 30-megawatt natural-gas-fired cogeneration plant, which operates at 66 percent overall net efficiency. It is also called a combined heat and power plant because it generates electricity to run lights and equipment, and it also captures the plant’s waste heat to produce steam for heating, ventilation, and air conditioning for much of the 12.5 million square feet of the campus’s buildings. Waste heat from the plant also is used as a power source for a water chiller that fills a 3.8-million-gallon storage tank at night with cold water, which allows the university to reduce its peak daytime energy requirements by about 14 percent.
The fuel cell and its ancillary equipment will occupy a space about the size of a tennis court. It will form the centerpiece of UC San Diego’s Energy Innovation Park on the east side of the main campus, which includes:
- High-efficiency, 5.75-kilowatt sun-tracking concentrating photovoltaic array made by Concentrix Solar;
- A compressed natural gas (CNG) fueling station for 13 CNG service vehicles, including two delivery trucks, two street sweepers, three sedans, three pick-up trucks, and three buses. Natural gas fuel produces lower emissions than traditional gasoline – 10 percent less carbon dioxide compared to diesel and 30-40 percent less than equivalent gasoline-fueled vehicles; and
- A chiller plant that produces the cold water required to cool the nearby Moores UCSD Cancer Center and Shiley Eye Center.
In the future the energy park will have an array of additional technologies:
- An electric-vehicle charging station;
- A second chiller plant with 300 kilowatts of cooling capacity that will be powered by the fuel cell’s waste heat to cool the Cancer Center, Shiley Eye Center and other UC San Diego medical treatment, research and office buildings nearby; and
- An energy-storage system that will stockpile four hours’ output of electricity from the fuel cell every night during off-peak hours and release the electricity to the campus energy grid during peak-demand hours in the afternoon.
The planned energy-storage system is eligible for an additional $3.4 million in State of California Self Generation Program incentives and could reduce UC San Diego’s peak energy demand by 6 percent.
“The university’s increasingly sophisticated microgrid will integrate all the campus’s production, consumption and stored power and cooling water into one of the most sophisticated energy-management systems anywhere,” said John Dilliott, energy and utilities manager for the campus. “We will soon be able to factor in the variable cost of imported electricity and optimize the production and consumption of electricity in our entire system with a high degree of cost and energy efficiency.”
The city of San Diego will make money by selling the Point Loma Wastewater Treatment Plant’s biogas, which is purified on site and injected into an existing gas pipeline that will supply three fuel cells being constructed, one at UC San Diego and two at City of San Diego sites. “This project and the uniqueness of the concept is anticipated to pave the way for similar future applications,” said Frank Mazanec, managing director of BioFuels Energy.
The three fuel cells are made by Danbury, Conn.-based FuelCell Energy, Inc. and use an electrochemical process to combine the methane fuel with oxygen in ambient air to produce electricity directly. Carbon dioxide and water vapor are also produced, but no nitrate or particulate pollutants are produced because there is no combustion.
The so-called directed biogas project is the first time that a FuelCell Energy power plant will be fueled by renewable biogas generated at a distant location.
The fuel cell being built at UC San Diego is one of the largest fuel cells in the nation to use directed biogas from a wastewater treatment plant,” said Kenneth J. Frisbie, managing director of the Encinitas, Calif.-based BioFuels Energy.
