Sandia Labs Covers Mixed Waste Landfill

vegetation

Environmental managers Mike Mitchell and Don Schofield check on the establishment of the new vegetation on the MWL cover. Photo courtesy of Randy Montoya.

The Environmental Restoration Project at Sandia National Laboratories reports the successful construction of an alternative evapotranspirative cover at the Mixed Waste Landfill (MWL) in September. The 2.6-acre site is located in Technical Area 3 in the west-central part of Kirtland Air Force Base in New Mexico.

The protective cover consists of four engineered layers, including three layers of compacted soil and a biointrusion rock barrier that will keep burrowing animals out of the former disposal areas. Together, these four layers and the native plants will control water infiltration, thus isolating the wastes from the accessible environment. Because the cover is constructed without rigid layers, it can accommodate differential subsidence without undue impairment of its performance.

The MWL was established in 1959 as a disposal area for low-level radioactive waste generated by Sandia's research facilities. Low-level radioactive waste and minor amounts of hazardous waste were disposed in the MWL from 1959 through 1988. Approximately 100,000 cubic feet of waste containing about 6,300 curies of activity (in 1989) were disposed of in the landfill. Over time, the radioactive materials in the landfill decay and become less hazardous.

The MWL has been monitored since 1969 and actively studied since 1991. An extensive investigation effort provided the technical foundation for the determination that the landfill is not expected to contaminate groundwater and does not represent an unacceptable risk to human health and the environment.

After the extensive investigation, public meetings and a public hearing, the New Mexico Environment Department (NMED) Secretary issued the final order in 2005 selecting an evapotranspirative cover with a biointrusion rock barrier as the selected remedy. After a review of competitive bids, Sandia awarded the construction contract to a local, small business. Cover construction was completed on schedule, near budget and without any safety incidents.

The NMED regulates the corrective action of the MWL as well as the implementation of institutional controls and long-term monitoring and maintenance. Sandia and DOE continue to provide quarterly progress reports to the NMED. In addition, the final order requires compilation of a report that re-evaluates the feasibility of excavation and analyzes the continued effectiveness of the selected remedy every five years. Construction of the MWL alternative cover will be documented in the Corrective Measures Implementation Report which will be submitted to the NMED for approval.

"The groundwater, soil gas and the cover will be monitored long-term to ensure performance and the protection of human health and the environment," said ER project task leader Mike Mitchell.
