Electro-Chemical Devices, Inc.
T80 Universal Transmitter
Process and plant engineers in search of a powerful process analyzer for multiple analytical measurements will find that the Model T80 Universal Transmitter from Electro-Chemical Devices, Inc. provides a versatile, easy-to-use, economical solution for virtually all liquid analytical measurements.
Featuring a highly intelligent digital transmitter protocol, the T80 Universal Transmitter simplifies process measurement and reduces maintenance costs for seven common industrial plant parameters. Process measurement has never been easier or more affordable than with the T80’s virtually plug-and-play capabilities, which simplify daily operations and maintenance while reducing instrumentation costs simultaneously.
The ECD Model T80 Universal Transmitter is a single channel transmitter designed for the continuous measurement of multiple parameters in a general-purpose industrial environment: pH, ORP, pION, Dissolved Oxygen, Turbidity, Conductivity or Resistivity. The Model T80 digitally communicates with any ECD Model S80 Intelligent Sensor and automatically conﬁgures the transmitter’s menus and display screens to the measured parameter. The Model T80 automatically configures to any of the listed measurements so that there is no need to inventory multiple instrument types, saving time and reducing plant operating costs.
The T80 Universal Transmitter is flexible and user-friendly. It offers membrane switch navigation, a simple menu structure and soft key menu choices and an easy-to-read 2 ¾ -x- 1 ½ inch LCD display. The T80 accepts any S80 intelligent sensor or any standard pH, ORP or pION sensor with solution ground using the optional T80 input card. It is available with 4-20 mA output with MODBUS RTU on 24 VDC and 110/220 VAC instruments. The T80 can be configured with optional HART 7 communication and an optional three alarm relay.
Vindum Engineering, Inc.
CV Series Valves
Vindum Engineering, Inc. (VEI) announces the release of its patented high pressure and high precision CV Series Valves, capable of continuous operation at pressures up to 20,000 PSI. Either On-Off or 3-Way/4-Position models are available. This patented VEI valve design can be used in high temperature applications and/or with corrosive fluids, further enhancing its operating envelope.
This high-pressure model is pneumatically operated via a set of small, low voltage pilot valves. The valves are available in a wide range of seal materials as well as corrosion resistant wetted parts (Stainless Steel or Hastelloy C-276), with either 1/8 or 1/4 inch fittings for high pressure tubing.
This new valve maintains a constant internal fluid volume and does not trap any fluid within the valve body when switched. This is one of the unique aspects of VEI’s patented valve design that delivers superior, reliable performance in a wide range of operating environments.
Fluid Components International
The ST100 Series Flow Meter sets a new industry benchmark in process and plant air/gas flow measurement, delivering unsurpassed adaptability and value to meet plant gas flow measurement applications for today and tomorrow.
The ST100 Flow Meter’s graphical, multivariable, backlit LCD display/readout brings new meaning to the term “process information”. It provides the industry’s most comprehensive information with continuous display of all process measurements and alarm status, and the ability to interrogate for service diagnostics.
The user-friendly ST100 stores up to five unique calibration groups to accommodate broad flow ranges, differing mixtures of the same gas and multiple gases, and obtains up to 1000:1 turndown. An optional, patent-pending SpectraCal Gas Equivalency calibration method lets users select and switch between 10 common gases. An on-board data logger with an easily accessible, removable 2-GB micro-SD memory card capable of storing 21 million readings comes standard.
The ST100 offers three different types of flow sensors to best match user applications. The fast-response FPC-style is a fast response features an integral flow conditioner and protective shroud optimized for compressed air and clean gas applications. The fast-response, general purpose FP-style features a protective shroud and is the sensor used with FCI’s VeriCal in-situ calibration option. For wet or dirty gases, or erratic flows, the unshrouded S-style facilitates easy cleaning and provides a smoothed response.
The ST100 can be calibrated to measure virtually any process gas, including wet gas, mixed gases and dirty gases. The basic insertion style air/gas meter features a thermal flow sensing element that measures flow from 0.25 to 1000 SFPS (0.07 NMPS to 305 NMPS) with accuracy of ±0.75 percent of reading, ±0.5 percent of full scale.
Designed for rugged industrial processes and plants, ST100 Flow Meters include service up to 850ºF and are available with both integral and remote (up to 1000 feet) electronics versions. The ST100 is agency approved for hazardous environments, including the entire instrument, the transmitter and the rugged, NEMA 4X/IP67 rated enclosure. Instrument approvals in addition to ATEX and IECEx include FM and FMc.
FPI Mag Flow Meter
Municipal and industrial engineers will find McCrometer’s FPI Mag (Full Profile Insertion) Electromagnetic Flow Meter features the new M-Series Converter, providing excellent accuracy to ±0.5% of reading and has obtained CSA certification to UL 61010-1 and CSA C22.2 No.61010-1-04, expanding the markets and applications for this meter.
Featuring an advanced filtering algorithm, McCrometer’s M-Series Converter supports FPI Mag Flow Meter accuracy of ±0.5% of reading from 1 to 32 ft/s and ±1% from 0.3 to 1 ft/s. The M-Series Converter offers many other new features, including built-in dual 4-20 mA outputs for communication flexibility, additional programmable outputs to support SCADA systems, and a simplified menu structure for ease of use.
The FPI Mag installs without service interruption making it ideal for retrofits, upgrades, and maintenance projects and sites never metered before. The hot tap installation reduces installation time by eliminating the need to de-water lines or cut pipe, saving customers up to 45%.
The FPI Mag is available for forward-flow only or a bi-directional measurement for line sizes from 4 to 138 inches. The flow sensor comes pre-calibrated from McCrometer’s NIST traceable Calibration Lab and requires no recalibration in the field.
Typical municipal water applications for the FPI Mag include wells, booster stations, effluent, filter balancing and backwash, pumping stations, UV dosing, and potable water distribution. The product also supports applications in a wide range of industrial process plants including chemical, electric power, food/beverage, oil/gas refining, metals/mining, pulp/paper, and more.
GF Piping Systems
GF Piping Systems has introduced the second generation Signet 9900 Transmitter featuring a Batch Controller option, along with all the proven features of the original model. The new Signet 9900 Transmitter (Generation II) supports multiple parameters that include flow, pH/ORP, Conductivity/Resistivity, Salinity, Temperature, Pressure, Level, and 4 to 20 mA Signals, and also Batch Systems.
Customers can convert their second generation 9900 Transmitter to a Batch Controller System by simply plugging in the new Batch Module and Relay Module, thereby maintaining the product’s original intent of consolidating multiple platforms into one while increasing their service level and reducing inventory.
The 9900 features an extra large (3.90” x 3.90”) auto-sensing backlit display that allows visibility at 4-5 times the distance of other transmitters. This highly illuminated display and large characters reduce the risk of misreading or misinterpreting the displayed values. The display shows separate lines for units, main and secondary measurements as well as a dial-type digital bar graph. Output accuracy is ±32 μA maximum error @ 25ºC @ 24 VDC with resolution of 6 μA or better. Other capabilities include relay and warning LEDs, and an intuitive menu for easy programming. Standards and approvals include NEMA 4X/IP65, CE, UL, CUL, RoHS and China RoHS.
The new 9900 Batch Control System is well suited for batch processes, filter backwash initiation, chemical addition, and canning and bottling. Other applications fulfilled by the 9900’s multi-parameter capabilities make it ideal for water and wastewater treatment, reverse osmosis, deionization, chemical dosing and delivery, metal and plastic finishing, fume scrubbers, cooling towers, and all types of filtration.
Select Fabricators, Inc.
Select-A-Shield RF EMI Shielded tents are used for everything from pre-compliance testing to secure communications. To assure shielding effectiveness during entry and exit, Select Fabricators, Inc. has developed a vestibule for its Select-A-Shield walk-in enclosures. With most walk-in enclosures, opening the door can immediately degrade shielding effectiveness resulting in possible data capture compromise or data corruption. With the addition of the Select-A-Shield vestibule, which is integral to the enclosure, the shielding environment is kept intact for consistent shielding performance.
In a typical 9’ wide, x 12’ length Select-A-Shield tent, the vestibule is situated in the right-hand front corner. 3’ x 4’, in size, the vestibule provides entry for personnel via a separate single door double magnet (patent pending) closure system which opens out. The vestibule has its own separate conductive floor, door,and inner walls apart from the tent itself which allows maximum isolation for continuous testing or examination. The door opening to the main compartment opens inwards, making entry and exit easier.
Select-A-Shield RF EMI shielded enclosures with vestibules typically include a white ESD liner and ventilation. “Ventilation is necessary when people occupy a RF EMI shielded tent”, stated Lynne Woodworth, chief development officer at SELECT, “SELECT’s fan and vent system is RF EMI shielded to preserve the shielding effectiveness of the structure. The white ESD liner not only protects against static, it also helps technicians read and record data against a neutral, brighter background.”
Select-A-Shield RF / EMI enclosures are constructed with RoHS compliant, durable, lightweight, Silver/Copper/Nickel, Nova Select fabric, SELECT’s proprietary highly conductive material. Shielding effectiveness for a vestibule measures -73 dB with both doors closed at 916 Mhz. A double wall RF EMI shielding tent with ESD liner yields an average SE of -78 dB average from 150 kHz to 18 GHz without the vestibule.
“We developed this US-based fabric to yield high conductivity for the widest range of applications,” said Woodworth. “We’ve done everything from die-cut parts to a shielded enclosure large enough to hold a tractor. The possibility to design shielding that assures RF EMI isolation from off-the shelf standard configurations to custom designs is what drives SELECT.”
Select-A-Shield RF EMI products are ideal for numerous applications including wireless device development and testing, secure communications, satellite communications testing and isolation, EMC pre-compliance, medical and aerospace equipment shielding, cellular and computer forensics, and RFID shielding for commercial and industrial settings. Because Select-A-Shield products can be customized to almost any size and option configuration, application suitability is endless.
Air Cycle Corp.
For larger facilities (over 150,000 square feet), Bulk Pickups offered by Air Cycle can provide a cost effective solution for recycling large amounts of intact or crushed lamps, ballasts, batteries, or electronic waste.
How Does It Work?
- Request a quote, or schedule a pickup online or by phone (800-909-9709). Pricing depends on your facility location and quantity of waste picked up.
- The recycling team will coordinate a pickup date that works best for you.
- Your packaged waste is picked up and delivered to a certified recycling partner located across the country.
- Once the waste has been recycled, you will receive a Certificate of Recycling, confirming the proper handling of your waste.
Air Cycle Corp.
EnviroPure Food Waste Diversion System
The EnviroPure Food Waste Diversion System by Air Cycle is an organic, self-contained, continual feed system that has been designed to transform food waste into a greywater effluent that can be safely disposed of into existing municipal water systems. The system is a great fit for any commercial kitchen operation such as hotels and schools. EnviroPure eliminates transportation costs for food waste, reduces janitorial labor and supply costs, and creates positive environmental impacts.
EnviroPure handles virtually any type of food waste including vegetables, fruits, meat, fish, poultry, dairy products, bones, shells and pits, with complete decomposition typically occurring within 24 hours. The system creates a positive environmental impact and is low maintenance with no odors, no sludge buildup, and no clean outs.
Air Cycle Corp.
Rodale Institute CDS
The Rodale Institute CDS by Air Cycle generates sanitizer and detergent from salt, water, and electricity while eliminating costs and the carbon footprint of shipping large quantities of chemicals. The system is recognized by EPA, FDA, and CDC, and produces cleaning solutions on-demand, as-needed. The units are constructed from durable 300 series stainless steel and there are models available for every facility size and application.
The system has been EPA registered and CDC recognized as a disinfectant, which has been FDA approved for use in food processing environments. It can also be used across several markets such as hospitality, entertainment venues, healthcare, universities/schools, office buildings, agriculture, and in food service and processing.
Air Cycle Corp.
EasyPak Pre-Paid Recycling Containers
EasyPak Pre-Paid Recycling Containers are the safe and easy way to recycle your facilities’ fluorescent bulbs, batteries, ballasts, and electronics. One price includes everything you need: the UN Certified recycling container, shipping to the recycling center, recycling fees, and certificates of recycling.
In order to begin using the containers, go to Air Cycle’s website and follow three easy steps. First, you can select the type of contains you’ll need, such as lamp, battery, and electronics recycling containers. You will then receive your selected containers in the mail and can begin filling them with waste. Return the filled containers for recycling when ready. It’s that simple.
Air Cycle Corp.
The Bulb Eater
The Bulb Eater Lamp Crusher by Air Cycle crushes spent fluorescent lamps of any length into 100% recyclable material while capturing over 99.99% of the vapors released. The system, which is mounted to a 55-gallon container, can hold up to 1350 4-foot fluorescent lamps.
The lamp crusher unit is equipped with a side-mounted dust filter unit containing the highest quality H.E.P.A. filter available. This works in conjunction with an activated carbon filter located in the steel canister. The activated carbon filter actively captures and neutralizes the mercury vapor released from the lamps during crushing.
A recent study showed non-detectable levels of escaped mercury vapor even after crushing 1500 lamps. A new safety control panel has also been added, giving the operator added security by monitoring seven aspects of the machine to better ensure operator safety.
In addition to providing EPA and OSHA compliance, the Bulb Eater Lamp Crusher frees up valuable storage space normally filled with boxes of spent whole lamps, reduces handling and related labor costs, and typically cuts recycling costs by 50% or more.
The Bulb Eater is capable of crushing straight lamps of any length, U-Tube lamps (Model VRS-U only), and even a 4-foot fluorescent lamp in a single second. The product reduces labor by 20 hours per 1,000 lamps, saves up to 50% on recycling costs, and minimizes storage space by 80%.
Neptune Chemical Pump Co. Inc.
Abaque Series Peristaltic Pumps
Neptune Chemical Pump Co. is pleased to announce the addition of the Abaque Series Peristaltic (Hose) Pump product line to its portfolio for the Americas. All Abaque Series pumps sold in the Americas will now be manufactured and shipped from PSG’s Neptune facility in North Wales, PA. The move is being made to better align the Abaque line with other PSG products and services that address the same primary market segments. The Abaque pumps are still available in 9 different models/sizes—from the AB10 to the AB100—with flow rates ranging from .07 to 211 gpm (.015-48 m3/hr).
The Abaque Series pumps feature a seal-free design that eliminates leaks and product contamination, which enables them to handle a wide array of challenging pumping applications in the oil and gas, chemical process, industrial and municipal water treatment, paint and coatings, and mining industries. The pumps, which can run in either forward or reverse, are self-priming and offer suction-lift capabilities to 29.5 feet, as well as the ability to run dry continuously without adversely affecting the pump’s performance. Ductile-iron and steel construction enables the pump to offer maximum discharge pressures as high as 217 psi.
Abaque Series pumps can be ordered as bare-shaft pumps or with a variety of drive options. Standard drive configurations include C-face gear reducer or C-face gear reducer with TEFC, explosion-proof or single-phase motors.
Fluid Components International
FS10A Analyzer Flow Switch/Monitor
Water and wastewater operations and plant engineers in search of a flow switch/monitor to ensure flow to their water or gas sampling systems or analyzers will find their solution in the Model FS10A Analyzer Flow Switch/Monitor from Fluid Components International (FCI). No matter how sophisticated a fluid analyzer system may be, it will be ineffective if a sample flow fails to reach the analyzer sensor. The most advanced systems in the world cannot provide accurate results without a valid fluid sample. That’s why FCI developed the advanced FS10 Analyzer Flow/Switch Monitor.
The FS10A Flow Switch/Monitor is designed for use with tubing from 1/8 inch to ½ inch and the electronics may be either integrally mounted or remote mounted from the sensor element. It is extremely sensitive to low flow rate detection, there are no moving parts to foul or clog, and there are no cavities, orifices, or dead-legs to trap or contaminate samples.
FS10A is suitable for application in liquid or gas analyzer sampling systems. It is small, lightweight, and features a choice of electronic outputs including open collector, relay, and
4-20mA outputs. Limit alarms are user programmable for time delay and/or hysteresis. An on-board 10-LED array provides at-a-glance visual indication to the user of flow rate and whether the alarm limit has been tripped. All FS10A set-up parameters can be performed via its two front panel push buttons or via a PC over its RS232C I/O. Its exclusive “learn” mode facilitates easy user set-up of flow range zero and span settings.
Water and wastewater end-users and system integrators will find FCI’s FS10A provides an overall solution for sampling system and analyzer flow assurance. With its advanced electronics and reliable thermal dispersion flow sensing technology, it will ensure the highest integrity process analysis without interruption.
LiteEarth Capping System
LiteEarth is an impermeable capping system for the long-term cover of landfills, coal ash, gypsum deposits, and land reclamation projects. LiteEarth utilizes proven components and design to save money, resources, time and the environment. The system permanently combines the latest synthetic turf with EPDM geomembrane into a lightweight, single-ply composite. The impermeable EPDM membrane offers flexibility and durability to resist cracking and easily conform to the terrain.
Synthetic grass provides natural looking cover 24/7/365 days a year, and eliminates costly and environmentally damaging fertilizers, pesticides, fungicides, and mower exhausts required for natural grass maintenance. The composite is delivered to project site in pre-manufactured size and length specifications, and only layout, positioning, and seaming is necessary on site. This patent pending system is the only EPDM-synthetic grass composite of its kind.
For years, Walchem has offered the WebMasterONE control in conjunction with Turner Designs Little Dipper online fluorometer, to accurately measure and control the concentration of scale or corrosion inhibitors in cooling tower and boiler applications. Now the Opti-Check fluorometer is available to ensure that the calibration of the online sensor is accurate. A low cost PTSA version, and an affordable PTSA/Fluorescein version, is available.
The Opti-Check handheld fluorometer requires low maintenance, is easy to use, and comes in a durable dustproof, watertight (IP 67) package. The product is sensitive to less than 1 ppb of fluorescent dye and provides better control of treatment chemicals.
